JLA VortexAir Macerator
The JLA Vortex Air macerator utilises the latest in motor control and diagnostics tools to minimise machine downtime whilst our SmartFlow™ maceration system ensures maximum performance
Quiet operation
The quietest full-size macerator on the
market at 62.0dBA
Multi-cycle
To suit all healthcare facilities with eco (16L of water) and Heavy (27L of water)
Intuitive display
Provides status of cycle during operation and time remaining to users
Working smarter to keep your teams safer
At JLA, we understand that machine downtime is not just disruptive, but can pose an infection control risk.
The Vortex Air contains the most comprehensive diagnostics tools and sensors ever seen on a hospital macerator. Each unit is also tested and optimised to macerate our range of medical pulp products, ensuring your machine is running in even the most heavy-duty environments.
Why choose a single-use disposable system?
- Eliminates cross infection risk from reusable bedpans.
- More convenient and hygienic.
- Zero aerosols released during disposal, eradicates risk of transmission via droplets.
- Hands-free system reduces number of potentially infected touch points.
- Immediate disposal reduces potential risk of contamination spray, splash backs, or spillages during cleaning.
- Use significantly less water than bedpan washers and requires cold water to process pulp products resulting in less energy consumption per product.
Specifications
JLA VortexAir Macerator Specifications
JLA VortexAir Macerator Specifications
| Cycle time (standard) | 120 seconds |
| Cycle time (heavy duty) | 140 seconds |
| Cycle time (eco mode) | 95 seconds |
| Weight | 76kg |
| Capacity | 6 small, 4 med or 2 large |
| Closing mechanism | Automatic (via foot sensor) |
| Opening mechanism | Automatic (via foot sensor) |
| Outside dimensions | 427 x 628 x 1027mm |
| Drain outlet | 2″ P trap (included) |
| Water inlet | 3/4 BSP (male) |
| Water usage (standard) | 23L |
| Water usage (heavy duty) | 27L |
| Water usage (eco mode) | 16L |
| Required flow rate | 12L/min (minimum) |
| Sound level | 62 dBA 9average) |
Product documentation
Total Care
A unique, all-inclusive package, specially designed for you.
- Market-leading equipment with no upfront payments, repair bills or call-out charges – ever
- Installation at no extra cost
- Guaranteed local engineer response
- 24/7/365 support from friendly advisors
- Access to myJLA, with billing, essential documents, engineer booking and support in one place
- Round-the-clock monitoring to minimise downtime – we sort issues before you know about them
- Keep an eye on your energy usage with live bill estimates and CO2 emissions
